These Are The Fastest Tamiya RC Motors:(Vehicles & Mini 4WD)

Are you in search of the ultimate Tamiya motor? Do you want to know which one reigns supreme in terms of speed? The answer might surprise you! In this article, we will reveal the fastest Tamiya motor for cars and trucks, as well as the fastest Tamiya RC Mini motor and give you all the details on its impressive performance capabilities.

The fastest Tamiya motor for RC cars and trucks is Tamiya HP Transpeed with 72000 rpm at no load, while the fastest Tamiya motor for RC Mini is a Plasma-Dash motor with 29000 rpm at no load. The Plasma-Dash has been discontinued by Tamiya.The next best option are the Hyper-Dash motors or the Sprint-Dash motor.

You’ll learn about their features and specifications, as well as how they compare to other Tamiya motors. But that’s not all – we’ll also provide tips on how to get the most out of these high-speed motors. Whether you’re a racing enthusiast or simply looking to upgrade your current setup, this article has something for you.

By the way, you can also check out this article if you are interested in learning more about how fast Tamiya RC cars can go.

What Is The Fastest Tamiya RC Motor?
Title in a red background

Fastest Tamiya motor for RC cars/trucks

Tamiya’s HP Transpeed is the fastest motor on the market for RC cars and trucks. This high-performance brushless motor is specifically designed for on-road track racing and is based on LRP X12 motors. It is available in a range of versions, featuring different rotor sizes and power levels to suit a variety of racing needs. The 12mm version offers higher RPM but has less torque compared to the 12.5mm version.

All Tamiya Transpeed motors are sensored and feature variable timing, making them highly responsive and reliable. Whether you’re a seasoned RC racing enthusiast or new to the sport, the Tamiya HP Transpeed is an excellent choice for anyone looking for top-notch performance and speed.

In terms of specification, the Tamiya HP Transpeed is the highest spec motor that Tamiya has to offer. It is available in power levels ranging from 9.5T to 4.5T, so you can find the perfect motor to match your RC vehicle and racing style. With its impressive speed and top-of-the-line features, the Tamiya HP Transpeed is a must-have for any serious RC racing enthusiast.

Rotor DiameterMotor PowerSensorPeak RPM at 7.2VTorqueKV
12.5mm7.5T – 3.5TYes7.5T: 33.840 rpm, 6.5T: 38.800 rpm, 3.5T: 72.000 rpmNot disclosed7.5T: 4700, 6.5T: 5400, 3.5T: 10.000
12mm9.5T – 6.5TYes9.5T: 29.520 rpm, 8.5T: 31.680 rpm, 7.5T: 35.280 rpm, 6.5T: 41.040Not disclosed9.5T: 4100, 8.5T: 4400, 7.5T: 4900, 6.5T: 5700

The Tamiya Transpeed HP motor is available on the Tamiya website, eBay, and most hobby shops.

For online, the best place that I found with the best selection of Transpeed motors; is eBay.

Fastest Tamiya motor for RC Mini

If you’re looking for the fastest Tamiya motor for your RC Mini, the Plasma-Dash is the way to go. This high-performance motor is distinguished by its black-coated metal housing and gray-color endbell cap, as well as the Tamiya motor sticker on its surface.

One of the standout features of the Plasma-Dash motor is its redesigned metal housing, which dissipates heat from inside the motor to extend its running life. Additionally, this motor uses user-replaceable carbon brushes, which can be easily swapped out using the Plasma Dash Brush Holder Set AO parts without the need to dismantle the motor.

In terms of specifications, the Plasma-Dash motor is the highest-spec Mini 4WD motor that Tamiya has ever released. It is so powerful that it has been banned from Tamiya-sanctioned races along with the Ultra Dash Motor and Jet-Dash Motor. Even the official tournament-approved Sprint Dash Motor and Power Dash Motor can’t keep up with the Plasma-Dash’s monstrous performance. If you want the best of the best, the Plasma-Dash is the way to go.

Voltage (V)Peak RPMTorqueCurrent (A)
2.4  – 3.025000 – 280001.4 – 1.94.1 – 5.2

The Plasma Dash has been discontinued by Tamiya so it’s becoming harder to to purchase one. Most online retailers say that it depends on availability and if they are, they are available in-store only. I’ve had a look and found Ali-express and eBay the most likely option.

It’s always worth asking in your local hobby shop.

Want to make your Mini 4WD faster? Consider reading my article: How To Make A Tamiya Mini 4WD Faster In 5 Steps

Is The Tamiya Plasma Dash Ideal For Any Track?

The answer is a definate NO. Super fast motors are designed for straight tracks.

If you are racing on a more technical course, you need to consider using a motor that is better suited.

A Plasma Dash is going to fly off the track as soon as it hits a sharp bend!

The Tamiya Plasma Dash Motor Has Been Discontinued By Tamiya

I contacted Tamiya USA support and asked why the Plasma has been discontinued. All they could say was; “Tamiya Inc. in Japan does not tell us why items have been discontinued.”

I then asked which is the next fastest motor; They recommended that any of the Hyper-Dash motors or the Sprint-Dash motor would be the fastest.

You can check these motors out by clicking this link that Tamiya support provided; https://www.tamiyausa.com/shop/mini-4wd/tune-parts/racing-motors/

You can also check out the selection of Tamiya Hyper-Dash motors and the Sprint=Dash motor here on Amazon.

Performance of Tamiya motors in different conditions (e.g. temperature, terrain)

The performance of Tamiya motors can vary depending on a number of factors, including temperature and terrain. Here is a summary of how Tamiya motors may perform in different conditions:

Temperature

Tamiya motors are designed to operate within a certain temperature range and may experience a reduction in performance if they exceed this range. For example, high temperatures may cause the motor to overheat and potentially fail, while low temperatures may cause the motor to become sluggish or unresponsive. It is important to ensure that your motor is operating within its recommended temperature range to maintain optimal performance.

Terrain

The performance of Tamiya motors may also be affected by the type of terrain they are used on. For example, off-road motors are designed to handle rugged terrain and high torque demands, while on-road motors are designed for smooth surfaces and high speeds. Using a motor that is not well-suited to the terrain you are driving on may result in reduced performance or even damage to the motor.

Load

The performance of Tamiya motors may also be affected by the load they are subjected to. For example, a motor that is running at or near its maximum load capacity may experience a reduction in performance or even failure. It is important to select a motor that is appropriately sized for the load you will be subjecting it to in order to maintain optimal performance.

It is important to consider the specific conditions that your Tamiya motor will be subjected to in order to ensure optimal performance. By selecting a motor that is well-suited to your needs and operating it within its recommended parameters, you can maximize its performance and extend its lifespan.

Types of Tamiya motors available

Tamiya is a Japanese manufacturer of radio-controlled (RC) vehicles and accessories, including electric motors. Here is a list of some of the types of motors that Tamiya offers.

Brushed motors

These are the most common type of electric motors used in RC vehicles. They have a simple construction with a stator (stationary part) that houses the windings, and a rotor (rotating part) that consists of a set of wound copper wire armature coils.

Brushed motors are generally less expensive and require more maintenance than brushless motors, but they are also widely available and easy to use.

Brushless motors

These motors have a more complex construction with a stator that contains permanent magnets, and a rotor that has windings instead of armature coils.

Brushless motors are generally more efficient and require less maintenance than brushed motors, but they are also more expensive and may be more difficult to use for beginners.

Super Stock motors

These are high-performance motors designed for use in Tamiya’s racing machines. They are capable of reaching speeds of up to 20,000 RPM and are available in a range of power levels.

HP Transpeed motors

These are also high-performance motors designed for use in RC cars and trucks. They are capable of reaching speeds of up to 26,000 RPM and are available in a range of versions with different rotor sizes and power levels.

Mini 4WD motors

Tamiya Mini 4WD motors are specifically designed for use in Tamiya’s Mini 4WD vehicles. They are known for their durable construction and are available in a range of power levels to suit a variety of racing needs.

Whether you’re a seasoned Mini 4WD enthusiast or new to the sport, Tamiya Mini 4WD motors are an excellent choice for anyone looking for top-quality performance and reliability.

Other specialized motors

Tamiya also offers a variety of other specialized motors for specific applications, such as boat motors and gear motors for robotic applications.

Keep in mind that this list is not exhaustive and is intended to provide an overview of the types of motors that Tamiya offers. You can find more information about the specific features and specifications of these motors on the Tamiya website or by contacting the company directly.

Comparison of brushed vs brushless Tamiya motors

Brushed and brushless motors are two types of electric motors commonly used in radio-controlled (RC) vehicles, including those made by Tamiya. Here is a comparison of the main differences between the two types of motors:

  • Construction: Brushed motors have a simple construction with a stator (stationary part) that houses the windings, and a rotor (rotating part) that consists of a set of wound copper wire armature coils. Brushless motors, on the other hand, have a more complex construction with a stator that contains permanent magnets, and a rotor that has windings instead of armature coils.
  • Efficiency: Brushless motors are generally more efficient than brushed motors because they have fewer moving parts and do not generate as much heat. This means that brushless motors are able to convert more of the electrical energy they consume into mechanical energy, resulting in better performance and longer run times.
  • Maintenance: Brushed motors require more maintenance than brushless motors because they have brushes that wear out over time and need to be replaced. Brushless motors, on the other hand, do not have brushes and therefore require less maintenance.
  • Speed: Brushless motors are typically faster than brushed motors because they can operate at higher RPMs and have a higher torque-to-weight ratio. This makes them ideal for high-speed applications such as racing.
  • Cost: Brushless motors tend to be more expensive than brushed motors due to their more complex construction and higher efficiency. However, the long-term cost of ownership may be lower for brushless motors due to their lower maintenance requirements.

Ultimately, the choice between a brushed and brushless motor will depend on your specific needs and preferences. Both types of motors have their own advantages and disadvantages, and it is important to carefully consider the trade-offs before making a decision.
